Transmission_line_pulse_reflections.gif (300 × 110 pixels, file size: 442 KB, MIME type: image/gif, looped, 240 frames, 12 s)
Summary
Transmission lines terminated by an open circuit (top) and a short circuit (bottom). A pulse reflects off the termination. Black dots represent electrons, and arrows show the electric field. Date 15 November 2014 Source Own work Author Sbyrnes321 Licensing I, the copyright holder of this work, hereby publish it under the following license: Creative Commons CC-Zero This file is made available under the Creative Commons CC0 1.0 Universal Public Domain Dedication. The person who associated a work with this deed has dedicated the work to the public domain by waiving all of their rights to the work worldwide under copyright law, including all related and neighboring rights, to the extent allowed by law. You can copy, modify, distribute and perform the work, even for commercial purposes, all without asking permission.
