Size of this preview: 800 × 600 pixels. Other resolution: 1,500 × 1,125 pixels.
Original file (1,500 × 1,125 pixels, file size: 220 KB, MIME type: image/jpeg)
Summary
Summary
| Description |
English: Example of a single industrial control loop; showing continuously modulated control of process flow. |
|---|---|
| Source |
Own work |
| Date |
2017-09-14 |
| Author | |
| Permission (Reusing this file) |
See below. |
| Other versions | Template:SVG |
